System.Formats.Nrbf 10.0.0-preview.4.25255.103

Prefix Reserved
.NET 8.0 This package targets .NET 8.0. The package is compatible with this framework or higher. .NET Standard 2.0 This package targets .NET Standard 2.0. The package is compatible with this framework or higher. .NET Framework 4.6.2 This package targets .NET Framework 4.6.2. The package is compatible with this framework or higher.
This is a prerelease version of System.Formats.Nrbf.
dotnet add package System.Formats.Nrbf --version 10.0.0-preview.4.25255.103






NuGet\Install-Package System.Formats.Nrbf -Version 10.0.0-preview.4.25255.103
This command is intended to be used within the Package Manager Console in Visual Studio, as it uses the NuGet module's version of Install-Package.
<PackageReference Include="System.Formats.Nrbf" Version="10.0.0-preview.4.25255.103" />
For projects that support PackageReference, copy this XML node into the project file to reference the package.
<PackageVersion Include="System.Formats.Nrbf" Version="10.0.0-preview.4.25255.103" />



                            Directory.Packages.props





<PackageReference Include="System.Formats.Nrbf" />



                            Project file
For projects that support Central Package Management (CPM), copy this XML node into the solution Directory.Packages.props file to version the package.
paket add System.Formats.Nrbf --version 10.0.0-preview.4.25255.103






#r "nuget: System.Formats.Nrbf, 10.0.0-preview.4.25255.103"
#r directive can be used in F# Interactive and Polyglot Notebooks. Copy this into the interactive tool or source code of the script to reference the package.
#addin nuget:?package=System.Formats.Nrbf&version=10.0.0-preview.4.25255.103&prerelease



                            Install System.Formats.Nrbf as a Cake Addin





#tool nuget:?package=System.Formats.Nrbf&version=10.0.0-preview.4.25255.103&prerelease



                            Install System.Formats.Nrbf as a Cake Tool

About

System.Formats.Nrbf exposes only one component: NrbfDecoder: a stateless, forward-only decoder class that can decode .NET Remoting Binary Format (NRBF) binary data from a stream.

You can think of NrbfDecoder as being the equivalent of using a JSON/XML reader without the deserializer.

How to Use

The NRBF payload consists of serialization records that represent the serialized objects and their metadata. To read the whole payload and get the root record, you need to call one of the NrbfDecoder.Decode methods.

The Decode method returns a SerializationRecord instance. SerializationRecord is an abstract class that represents the serialization record and provides three properties: Id, RecordType, and TypeName. It exposes one method, TypeNameMatches, which compares the type name read from the payload (and exposed via TypeName property) against the specified type. This method ignores assembly names, so you don't need to worry about type forwarding and assembly versioning. It also does not consider member names or their types (because getting this information would require type loading).

using System.Formats.Nrbf;

public class Sample
{
    public int Integer;
    public string? Text;
    public byte[]? ArrayOfBytes;
    public Sample? ClassInstance;
}

ClassRecord rootRecord = NrbfDecoder.DecodeClassRecord(payload);
Sample output = new()
{
    // using the dedicated methods to read primitive values
    Integer = rootRecord.GetInt32(nameof(Sample.Integer)),
    Text = rootRecord.GetString(nameof(Sample.Text)),
    // using dedicated method to read an array of bytes
    ArrayOfBytes = ((SZArrayRecord<byte>)rootRecord.GetArrayRecord(nameof(Sample.ArrayOfBytes))).GetArray(),
    // using GetClassRecord to read a class record
    ClassInstance = new()
    {
        Text = rootRecord
            .GetClassRecord(nameof(Sample.ClassInstance))!
            .GetString(nameof(Sample.Text))
    }
};

Main Types

There are more than a dozen different serialization record types. This library provides a set of abstractions, so you only need to learn a few of them:

  • PrimitiveTypeRecord<T>: describes all primitive types natively supported by the NRBF (string, bool, byte, sbyte, char, short, ushort, int, uint, long, ulong, float, double, decimal, TimeSpan, and DateTime).
    • Exposes the value via the Value property.
    • PrimitiveTypeRecord<T> derives from the non-generic PrimitiveTypeRecord, which also exposes a Value property. But on the base class, the value is returned as object (which introduces boxing for value types).
  • ClassRecord: describes all class and struct besides the aforementioned primitive types.
  • ArrayRecord: describes all array records, including jagged and multi-dimensional arrays.
  • SZArrayRecord<T>: describes single-dimensional, zero-indexed array records, where T can be either a primitive type or a SerializationRecord.
SerializationRecord rootObject = NrbfDecoder.Decode(payload); // payload is a Stream

if (rootObject is PrimitiveTypeRecord primitiveRecord)
{
    Console.WriteLine($"It was a primitive value: '{primitiveRecord.Value}'");
}
else if (rootObject is ClassRecord classRecord)
{
    Console.WriteLine($"It was a class record of '{classRecord.TypeName.AssemblyQualifiedName}' type name.");
}
else if (rootObject is SZArrayRecord<byte> arrayOfBytes)
{
    Console.WriteLine($"It was an array of `{arrayOfBytes.Length}`-many bytes.");
}

Additional Documentation

Feedback & Contributing

System.Formats.Nrbf is released as open source under the MIT license. Bug reports and contributions are welcome at the GitHub repository.
